Swing over bed: 32″

Distance between centers: 120”

Swing over cross slide: 22″

Swing in gap: 55″

Length of removable gap: 10″

Spindle bore: 9″

Spindle speeds (12): 5 – 300 RPM

Inch threads (48): 1-1/4 – 27 TPI

Metric threads (48): 0.5 – 14 mm

Inch feeds (48): 0.0032 to 0.5540

Metric feeds (48): 0.081 to 2.288

Leadscrew diameter: 2″

Leadscrew pitch: 2 TPI

Tailstock taper: #6

Tailstock quill diameter: 4-1/4″

Tailstock travel: 10-1/2″

Main motor : 20 HP

Volts: 220 / 440

Phase: 3

Cycles: 60 Hz

Amps: 52 / 26

Approximate dimensions: 206″ x 66″ x 95″ high

Shipping height: 65″ (on 4″ blocks w/DRO & Pendant removed)
